Classifieds

Used Decorating Machines

K1 CNC 1500

Fully automatic 3 color UV screen printing machine

Uninstalled by Kammann technicians. Machines were confirmed to be in running condition. Crated and ready to ship.

Features

• K31A XS 2-stage pretreatment unit for glass
• Infeed and outfeed accumulation conveyor
• Motorized CNC control for all variable movements of the machine, including adjustment of print image length and adjustment of article rotation
• 4-axis article holder controlled by programmable servo drive and single-capture tooling capable of holding one article between a base holder and nose cone for maximum control.
• Tiltable A-axis for conical articles, machine controlled via servo drive. Tilt angle +15° to -22°
• Optical sensor for article registration and existing print registration
• Air inflation for printing on thin-walled plastics or aluminum
• Built and installed in 2015 by Kammann Gmbh

Article and Printing Specifications

• Printable Article Shapes - Round, oval, flat/square, conical, articles with handles, etc.
• Article Diameter: Min: 20mm Max: 165mm
• Article Height: Min: 40 Max: 380
• Print Image Length: Max: 320mm
• Speed: Adjustable up to 900 articles/hour with 1-color print or up to 500 articles/hour with 3-color print

For more information, please click here

* Note: Machine specifications are believed to be correct but should be verified before purchasing.

K15 CNC-S10

Fully automatic 4 color UV screen printing machine with accumulation table

Uninstalled by Kammann technicians. Machines were confirmed to be in running condition. Crated and ready to ship.

Features

• Motorized CNC control for all variable movements of the machine, including computerized adjustment of print image length and adjustment of article rotation
• Indexing table with 10 article holder stations controlled by programmable servo drive, each with single capture tooling capable of holding one article between base holder and nose cone for maximum control

Article and Printing Specifications

• Printable Article Shapes - Round, oval, square, rectangular, tapered
• Article Diameter: Min: 20mm Max: 120mm
• Article Height: Min: 50mm Max: 300mm
• Print Image Length: Max: 240mm
• Speed: Adjustable up to 65 articles/minute (3,900/hour)

For more information, please click here

* Note: Machine specifications are believed to be correct but should be verified before purchasing.

K15 CNC-M15

Fully automatic 5 color UV screen printing machine with Kammann K31-MFS glass pre-treatment device and accumulation conveyor

Uninstalled by Kammann technicians. Machines were confirmed to be in running condition. Crated and ready to ship.

Features

• Seam register camera for article detection and registration
• Air inflation for printing on thin-walled plastics or aluminum
• DeCoSystem print quality inspection system
• Current number of impressions: 28,772,262
• Three electrical connections: 480 volt. 60 cycles, 3-phase
• Printing speed: adjustable up to 80 articles per minute (4,800 articles per hour). The maximum printing speed will vary depending on the size of the article, the length of the print image and the ability to feed the articles in/out of the machine at the proper speed.

Article and Printing Specifications

• Printable Article Shapes - Round or slightly conical
• Article Diameter: Min: 20mm Max: 120mm
• Article Height: Max: 350mm
• Print Image Length: Max: 300mm
• Speed: Adjustable up to 80 articles/minute (4,800/hour)

For more information, please click here

* Note: Machine specifications are believed to be correct but should be verified before purchasing.
